S8022 Pro Plus-16/24/32H High-Speed Sublimation Printer

Compatible with Epson i3200A1/A1-2, Epson S3200 and Kyocera EX600RC printheads.

Quantity & Color Options: Optional multi-head multi-color configurations: 16H/4C, 24H/6C, 32H/4C/8C

Print Width: 2200mm

Max Productivity: 1400㎡/h

Ink Configuration: C, M, Y, K; optional LM, LC, LK, LLK

SPECIFICATION

Product Introduction

Name: S8022 Pro Plus-16/24/32H High-Speed Sublimation Printer
Brand: Yilijet/Xenons Inkjet Printing Solutions
Availability: InStock
Rating: 5 (1 reviews)

S8000 Pro Plus -16/24/32H High-Speed Sublimation Printer

Designed for mass digital printing of home textiles, apparel and decorative fabrics. Available with various multi-head & multi-color printing configurations, it comes with a standard 2200mm print width and a maximum production output of 1400㎡/h.

Equipped with imported low-noise dual THK linear guides, maglev motors, magnetic grid drive system, framed straight-slot suction printing platform, triple-layer printhead protection and dual-layer circulating infrared drying system. Fitted with 15L large-capacity ink tanks and automatic negative-pressure ink supply system, it supports raw rolls up to Φ1000mm and enables stable non-stop 24-hour mass production. Featuring stable operation, high precision and powerful productivity, it serves as core production equipment for textile printing manufacturers’ large-scale production.

Core Advantages

✅ Premium Multi-Head Configuration, Max Output up to 1400㎡/h

Configured with Epson S3200 industrial printheads in optional 16H/24H/32H layouts, reaching a top printing speed of 1400㎡/h to easily handle bulk orders and peak-season production demands.

✅ 2200mm Printing Width for One-Pass Home Textile Production

The standard 2.2m working width is ideal for wide-size materials such as curtains, sofa fabrics and bedding without splicing, improving finished product quality and production efficiency.

✅ Maglev Drive for Stable Low-Noise High-Speed Operation

Combination of low-noise dual THK guides, maglev motors and magnetic grid positioning system eliminates shaking and noise at high speed, delivering precise printing and longer service life.

✅ Framed Straight-Slot Suction Printing Platform

Full-area uniform suction fits 22–110g sublimation transfer paper, keeping paper flat without wrinkles or deviation for consistent printing results.

✅ Three-Tier Printhead Protection Reduces Operating Losses

Three-way anti-collision design, base anti-scratch structure and laser height detection provide all-round printhead protection to avoid scratch damage and cut maintenance costs.

✅ 15L Large Ink Tank plus Automatic Negative-Pressure Ink Supply

15L large-volume ink storage with precise automatic negative-pressure control ensures steady uninterrupted ink feed to support 24-hour nonstop production.

✅ Dual-Circulation Infrared Hot-Air Drying for Instant Drying

Front & rear dual-sided hot-air drying ensures even heating, preventing ink bleeding and adhesion during high-speed printing to boost production efficiency.

✅ Large Roll Loading & Unloading to Minimize Roll-Replacement Downtime

Supports feeding rolls up to Φ1000mm and take-up rolls up to Φ450mm with automatic constant tension control, greatly improving continuous production efficiency.

✅ Intelligent Automation for Simple Operation & Easy Maintenance

Integrated automatic printhead cleaning & capping, intelligent ink feeding and production data management simplify operation and lower labor and maintenance costs.

Technical Specifications

Model: S8000 Pro Plus

Printhead Type: Epson S3200 Industrial Printhead

Printhead Quantity: 16H / 24H / 32H

Max Printing Speed: 1400㎡/h

Print Width: 2200mm

Print Media: Sublimation Transfer Paper

Ink Type: Sublimation Ink

Available Colors: C, M, Y, K; optional LM, LC, LK, LLK

Ink Tank Capacity: 15L

Ink Supply: Automatic Feeding with Automatic Negative Pressure Control

File Format: TIFF / JPG / EPS / PDF; compatible with RGB / CMYK

Print Platform: Framed Straight-Slot Suction Platform

Drive System: Imported Low-Noise Dual THK Linear Guides, Maglev Motor, Magnetic Grid System

Head Maintenance: Integrated Automatic Cleaning & Capping

Roll Handling: Max feed roll Φ1000mm; max take-up roll Φ500mm

Drying System: Dual Heating with Circulating Infrared Hot Air

Application Fields

Curtain & Home Textile Printing | Bedding Set Printing | Sportswear Printing | Swimsuit & Yoga Wear Printing

Outdoor Flag & Banner | Decorative Fabric Printing | Large Digital Printing Factories | 24-Hour Industrial Mass Production Lines
